Gokin Gokin GK-3-54HGb-480M 480W All Black GBC Single-Glass Solar Panel
Gokin Solar GK-3-54HGb-480M is a 480W all-black GBC solar module with a single-glass construction. It combines a clean appearance with high module efficiency and strong performance under changing temperatures and partial-shading conditions.Key Features 480W rated maximum power 23.5% module efficiency All-black GBC cell technology Single-glass construction with 3.2mm tempered glass Partial-shading optimisation Power temperature coefficient: -0.26%/°C 15-year product warranty 30-year linear power warranty Electrical Characteristics (STC) Maximum Power (Pmax): 480W Open-Circuit Voltage (Voc): 40.65V Short-Circuit Current (Isc): 15.00A Maximum Power Voltage (Vmp): 33.68V Maximum Power Current (Imp): 14.26A Power Tolerance: 0 to +3% Maximum System Voltage: 1500V (IEC) Maximum Series Fuse Rating: 25A Mechanical Parameters Cell Type: GBC Number of Cells: 108 (6 × 18) Glass: 3.2mm tempered glass Frame: Black anodised aluminium Junction Box: IP68 Output Cable: TÜV 1 × 4mm², (+)300mm and (-)200mm, or customised length Connector: MC4 compatible / MC4-Evo2 Dimensions: 1800 × 1134 × 30mm Weight: 21.4kg Protection Class: Class II Fire Rating: IEC Class C Operating and Load Ratings Operating Temperature: -40°C to +85°C NOCT: 45 ± 2°C Front-Side Maximum Static Loading: 5400Pa Rear-Side Maximum Static Loading: 2400Pa Hail Test: 25mm diameter hail at 23m/s Model: GK-3-54HGb-480M
$229.00
