Description
The WG-24S1220Z model is a non-isolated DC to DC converter, incorporating advanced synchronous rectification technology. It is distinguished by its high efficiency and compact power density. This model is specifically designed to convert a 24V input to a stable 12V output, with a maximum current capacity of 20A.
Key Features:
Compliance with RoHS and CE standards.
Exceptional efficiency rate of 95.7% at 24V input and 25°C ambient temperature.
Non-isolation between input and output for streamlined power transfer.
Compact dimensions, ensuring ease of integration and high reliability.
Operational capability in extreme temperatures as low as -40°C.
Rigorous 100% full load burn-in test to guarantee quality and durability.
Comprehensive protection features against short circuits, overloads, and low voltage scenarios.
Waterproof with an IP67 rating, ensuring suitability for a wide range of environmental conditions.
Applications:
Industrial and Alternative Energy sectors.
Golf Carts, Cars, Forklifts, and Electromotors.
Telecommunications infrastructure.
Marine applications including Boats and Yachts.
Medical equipment.
LED Marketplaces and various other fields.
Specifications:
Input Voltage Range: 18-36 V DC
Output Voltage: 12V DC
Output Current: 20 Amps
Output Power: 240 Watts
Efficiency: 95.7%
Dimensions: 64mm x 57mm x 22mm
This DC to DC Converter is an ideal solution for a range of applications requiring efficient and reliable voltage regulation.
