Description
Introducing the New Uninterruptible Power Supply Low-Frequency Pure Sine Inverter!
As a specialized solar service company, we offer quality products and comprehensive support. Our expertise ensures professional, efficient system design solutions tailored to your needs.
Inverter Uses:
Suitable for PV systems.
Ideal for RV modifications.
Compatible with lithium batteries.
Product Features:
Continuous power output.
Universal socket design for all appliance connections.
Fully isolated input and output.
Transformer isolation for power.
Optocoupler isolation for signals.
Independent auxiliary power.
High efficiency over 93%.
Constant power output with real short circuit protection.
SMT chip technology for reliable, stable output.
PWM regulated power, output voltage ±3%.
Specifications:
Rated Power: 6000W
Peak Power: 22000W
Battery Voltage: 48V
Dimensions: 650×220×180 mm
Weight: 39kg
AC Input Voltage Range: 170-260VAC (220V), 85-130VAC (110V)
Input Frequency: 45-65Hz
Battery Voltage Range: 48V
Output Voltage Range: 230V/240V±3% (Inverter mode)
Output Frequency: 50/60±1%
Utility Output Frequency Range: 50 Hz/60 Hz auto-tracking
Output Waveform: Pure sine wave
Efficiency: >85%
Transfer Time: ≤5ms
Compatible Battery Types: Lead-acid, colloidal, lithium-iron, ternary lithium, unconventional batteries
Charging Voltage Range: 48VDC
Protections: Short circuit, high/low voltage, overcharge, overload, high temperature
Overload Protection: Stops at 110%-120% load after 60 seconds, at 150% load after 10 seconds.
